Let us do some more basics with the “Spring Rich Client” 1.0.0 (SpringRC). Although it is time to give an overview of the entire architecture I won’t do this here, because I am a newbie with Spring and SpringRC. So we will just look into the steps how we get things running.

Update: See an older post for a good intro or this link collection for more information.

Startup

First of all we want to include a license prompt on the very first startup. If it is in pure text format surround the license with <pre>licenseText</pre>, save it to the classpath as /path/license.txt and do the following:

• Add the source code into LifecycleAdvisor

      private final Log logger = LogFactory.getLog(getClass());
      private static final String SHOW_WIZARD_KEY = "setupWizard.show";
      private Settings settings;
      @Override
      public void onPreStartup() {
          boolean showDialog = true;
          if (settings.contains(SHOW_WIZARD_KEY)) {
              showDialog = settings.getBoolean(SHOW_WIZARD_KEY);
          }
          if (showDialog && getApplication().getApplicationContext().containsBean("setupWizard")) {
              SetupWizard setupWizard = (SetupWizard) getApplication().getApplicationContext().getBean(
                      "setupWizard", SetupWizard.class);
              setupWizard.execute();
              settings.setBoolean(SHOW_WIZARD_KEY, false);
              try {
                  settings.save();
              } catch (IOException ex) {
                  logger.error("Can't save state.", ex);
              }    }    }
      public void setSettings(Settings set) {
          settings = set;
      }

• Add the following text into the application-context.xml

  <bean id="setupWizard" class="org.springframework.richclient.application.setup.SetupWizard">
      <property name="licenseTextLocation" value="/path/license.txt" />
  </bean>
  <bean id="xmlInternalSettings"
        class="org.springframework.richclient.settings.xml.XmlSettingsFactory"
        factory-bean="settingsManager"
        factory-method="getInternalSettings">
  </bean>
  <bean id="settingsManager" class="org.springframework.richclient.settings.SettingsManager">
          <property name="settingsFactory">
              <bean class="org.springframework.richclient.settings.xml.XmlSettingsFactory"/>
          </property>
  </bean>

  And insert <property name=”settings” ref=”xmlInternalSettings” /> into the lifecycleAdvisor bean’s property list.

• As last step you have to fill in the message text for this wizard into the message.properties file:
  setup.intro.welcomeTo = Welcome to
  setup.intro.title = TimeFinder!
  setup.intro.description = TimeFinder in one of its future releases will help you with automatic and manual timetabling.
  setup.cancel.title=Cancel Setup
  setup.cancel.message = Do you really want to exit the application?
  acceptLicenseCommand.label=I &accept the terms of this license agreement
  doNotAcceptLicenseCommand.label=I do ¬ accept the terms of this license agreement
  setup.license.title=License agreement
  setup.license.description=Please read the following license agreement carefully

The most of the xml code above is necessary to inject a new instance of Settings which will be created from the SettingsManager.

… Break …

Does anybody of you know, how I can do this in Java, not in ugly xml? Well, I could create the factory directly in the LifecycleAdvisor, but how can I do this dependency injection in Java (with Spring)?

… Okay, let us go further …

This settings object is then accessible within the LifecycleAdvisor because of the setSettings method and is necessary to save, if this wizard should be prompted on the next startup again. The xml-settings will be written to currentPath/settings/internal.settings.xml.
The used SetupWizard extends from AbstractWizard. This abstract class could be used for any other wizards: just add one or more AbstractWizardPages to the wizard and see this documentation. Here is the result:

Another cool feature is to show a progressbar on the splashscreen. This was very easy: add (or replace the existing) bean to the startup-context.xml file:

<bean id="splashScreen" class="org.springframework.richclient.application.splash.ProgressSplashScreen" scope="prototype">
        <property name="imageResourcePath" value="/de/peterk/springr/ui/images/splash-screen.png" />
        <property name="showProgressLabel" value="true" />
</bean>

Now I did an ugly hack. I want to change the colors of the progressbar. But only on the progressbar on startup, so we have to revert the following code:

Color myYellow = new Color(255, 225, 100);
Color myGreen = new Color(120, 208, 60);
UIManager.put("ProgressBar.selectionForeground", myYellow);
UIManager.put("ProgressBar.selectionBackground", myGreen);
UIManager.put("ProgressBar.foreground", myGreen);
UIManager.put("ProgressBar.background", myYellow);
UIManager.put("ProgressBar.border", new LineBorderUIResource(myYellow));

To revert these changes, please look into the method LifecycleAdvisor.onPreWindowOpen (see the resources section, I will not post it here – it is too stupid ;-))

Here is the result:

Views …

Hopefully I can create a next blog entry about the docking framework MyDoggy and the integration into SpringRC. Now it works like a charm – try it out! (see resources).

Today I will show what you can apply to all ‘component managers’ that are integrated in SpringRC.

First: there is one application per virtual machine. But there could be one or more ApplicationPages (JFrames) with several views (center, north, south, …). In our case (MyDoggy) there is only one ApplicationPage.

Normally you want to have more than one component per start-up page. To change this add the following xml to the application-context.xml:

<bean id="aLotOfViews" class="org.springframework.richclient.application.support.MultiViewPageDescriptor">
   <property name="viewDescriptors">
     <list>
        <value>view2</value>
        <value>initialView</value>
     </list>
   </property>
</bean>

And change the startingPageId in the lifecycleAdvisor bean to aLotOfViews. With the upcoming MyDoggy 1.5.0 enabled we can get this nice layout, which will be automatically saved(!):

Of course it is possible to use other layout manager like swing dockings:

… and more!

If you want to use custom components: just add them! I created a custom component with the open source Matisse GUI builder integrated in NetBeans. Here is the code how you can put this component into SpringRC:

public class CalculatorView extends AbstractView {
    protected JComponent createControl() {
        JPanel panel = getComponentFactory().createPanel(new BorderLayout());
        panel.add(new CalculatorPanel()/*created with Matisse*/, BorderLayout.CENTER);
        return panel;
    }}

To add this view to the startingPage do (aLofOfViews already references to this bean, so no changes are necessary there):

<bean id="view2" class="de.timefinder.core.ui.mydoggy.MyDoggyViewDescriptor">
        <property name="viewClass" value="de.timefinder.core.ui.CalculatorView" />
</bean>

One thing you have to know is: How to translate keys within this ‘external’ CalculatorView?

In Matisse do:

1. Click the button, where you want to translate the text
2. Then – in the property panel on the right side – click on the […] button
3. Select “Resource Bundle” instead of “Plain Text”
4. Use the messages.properties file for the bundle name
5. Insert the appropriate key (defined in messages.properties)
6. Use the following line to get the value (click on the “Format…” button) Application.instance().getApplicationContext().getMessage(“{key}”, null, null)

For all of the following components it is easier: do 1, 2, 3 and insert the key! This could be the new slogan for Matisse 😉

Now some more I18N. For example you want to display: “Result of $number!” you should use the following line in message.properties:

calculatorPanel.title=Result of {0} !

and get the formatted string via

Application.instance().getApplicationContext().getMessage("calculatorPanel.title", new Object[]{result}, null);

Another small point could be the ugly output of the standard java 1.4 Logger. We will now change the two-lined logging output into a one-lined. Actually this is a one-liner if you look for yourself into the resource section for the TFFormatter class:

java.util.logging.Logger.getLogger("de.timefinder").getParent().getHandlers()[0].setFormatter(new TFFormatter());

Tasks

In Swing you can use the Swing ProgressMonitor, but in SpringRC you should use the integrated ProgressMonitor to indicate the current progress of a task in the bottom right corner of the page:

With the factorial view of my example you can calculate, yes, factorials. I tried “50 000” and the calculation took nearly the same time as adding the number to the JTextArea …

So, use the ProgressMonitor in combination with the SwingWorker (I grabbed it from jdesktop, but you can use SpringRC’s Swingworker as well. Get the concurrent package from here or through maven. )

Now you can use the following code to execute a long running task:

ApplicationWindow aw = Application.instance().getActiveWindow();
final ProgressMonitor pm = aw.getStatusBar().getProgressMonitor();
String str = Application.instance().getApplicationContext().getMessage("calculatorPanel.startTask", null, null);
pm.taskStarted(str, -1);
SwingWorker sw = new SwingWorker() {
        BigInteger resultLong = BigInteger.ONE;
        //protected Object construct() in SpringRC's SwingWorker!
        protected Object doInBackground() {
            // now my long task and the progress indication
            for (int i = 2; i <= fac && !pm.isCanceled(); i++) {
                pm.worked(100 * i / fac);
                resultLong = resultLong.multiply(BigInteger.valueOf(i));
            }
            return resultLong;
        }
        //protected void finished()
        @Override
        protected void done() {
            // all of the following code will be called on the Event Dispatching Thread
            if (pm.isCanceled()) {
                output.setText("Canceled");
            } else {
                output.setText(resultLong.toString());
            }
            pm.done();
        }
    };
    //sw.start();
    //sw.clear(); // reuse would be possible with SpringRC's SwingWorker!
    sw.execute();

Conclusion

SpringRC offers us – as client-side-programmers – a bunch of powerful utilities to build our application fast and scaleable. Some parts are well documented; some parts not. But I think with relaunching the project in October ’08 (hopefully!) as Spring Desktop it will get a lot of support from even more users and maybe from the company SpringSource itself. Hopefully then the documentation will be better…

The most important point for me is that SpringRC is ‘only’ a sweat jar collection and not a layer between me and Swing.

Another point is that SpringRC uses dependency injection and NetBeans RCP uses the service locator approach e.g.
SomeInterfaceImpl impl = Lookup.lookup(SomeInterface.class).
instead of the setter injection in the very first example for SpringRC.
For others this could be one more argument against NetBeans RCP (not for me …)

Resources

• Another older, but very good tutorial is located here.
• Maybe it is interesting to know: in the updated version of the book Spring – A Developer’s Notebook the last chapter 9 is about the Spring Rich Client Project (author was Keith Donald).
• Here you can find part 1.
• Here you can download the project without the jars included in the SpringRC’s download (It is a NetBeans 6.1 project, so you can simply copy all jars of SpringRC into the lib folder and open the project with NetBeans. Then resolve references via right click or change the references directly; in nbproject/project.properties).
• Update: Other resources can be found here.

Today I will start a series about the great Swing framework called Spring Rich Client (SRC). The 1.0.0 version was released in March 2008 and it is not inactive as I thought before.

You can get more information about SRC from:

• the forum
• the German documentation or
• the English documentation.
• Update: other links and Part2

Why I listed the forum as the first point? Because for a beginner like me it was the best source of information (after the samples).

So, let us set up a hello world example.

• Download the Spring Rich Client 1.0.0 from here (19 MB, Apache License 2.0).
• Download my Hello World skeleton (a NetBeans 6.1 project, 60 KB) or use the spring-richclient-archetype from the download bundle of SRC, where you have to install maven before you can compile and run it.

If you use my Hello World skeleton you should open it in NetBeans, right click on the project node and resolve reference problems. Then go to the place where you have unzipped the SRC and add the first jar file. The other jar files should be added automagically for you.

The project with dependencies would be about 2.7 MB, it is not a small overhead, but okay, I think. As an example for the reader one can compare it to the minimal size of the NetBeans or Eclipse RCP.

Now it is time to start the project with F6 or Run->’Run Main Project’. You should see the frog-splashscreen and the final view:

Now let me explain several things that one could customize in SRC. Please see the Resources section for the result of customization.

As the first point I wanted to know how easy it is to introduce docking capabilities (vl docking). It was really easy!

• add spring-richclient-docking.jar and vldocking.jar
• and change 2 things in the richclient-application-context.xml file:
• change class of initialView to org.springframework.richclient.application.docking.vldocking.VLDockingViewDescriptor
• add a applicationPageFactory to the richclient-application-context.xml

Then you can add a new window to see the results of dragging:

• Create the class View2
• add the following to the richclient-application-context.xml:
• <bean id=”view2″
  class=”org.springframework.richclient.application.docking.vldocking.VLDockingViewDescriptor”>
  <property name=”viewClass” value=”de.peterk.springr.View2″ />
  <property name=”autoHideEnabled” value=”true” />
  <property name=”closeEnabled” value=”true”/>
  </bean>
• and you are done! Just start the application go to Windows->Show View->View2

Now,

how easy is it to use your own layout? Configuring the look and feel:

• Remove the lookAndFeelConfigurer and add instead:
  <bean id=”lookAndFeelConfigurer” class=”de.peterk.springr.ui.KunststoffConfigurer”></bean>
• remove looks.jar: 350 kb
• add kunststoff: 17 kb
• add the KunststoffConfigurer class to the source package

Okay, then changing the splash screen is trivial: just overwrite the splash-screen.png or change the path in the richclient-startup-context.xml file.

Now we should adjust the size of the view, this can be done with 2 lines in the method SimpleLifecycleAdvisor.onPreWindowOpen:

Rectangle rect = GraphicsEnvironment.getLocalGraphicsEnvironment().getMaximumWindowBounds();
configurer.setInitialSize(new Dimension(rect.width, rect.height));

And to translate the messages simply copy all property files to e.g. file_de.properties and translate them! In our case it means “cp message.properties message_de.properties”. If you want to add a translateable tool tip of the initalView-label just use:

• lblMessage.setToolTipText(getMessage(“initialView.toolTip”));
• in InitialView.createControl and add the property initialView.toolTip to the property file.

To set a keyboard shortcuts e.g. to leave the application. You need to add one line to the message.properties file

• exitCommand.label=Exit@ctrl Q

Another interesting action (in SRC they will be called commands) could be restart. So how can we add the action into the menu? You have to add

• restartCommand.label=Restart@ctrl R
• in the message.properties file and use
• Application.instance().start(); Application.instance().getActiveWindow().close();
• within your RestartCommand class. Then add
• <bean class=”de.peterk.springr.RestartCommand” />
• into the commands-context.xml (e.g. after <value>propertiesCommand</value> in fileMenu)

The final result is:

Resources

Here you can download the extended “hello more” sample (a NetBeans 6.1 project about 90 KB, without dep). The full project was 2.9 MB.

Conclusion

One can say that Spring Rich Client is a powerful jar collection :-). But I would say SRC is a great way for your next swing application!

It is very intuitive to use: the whole sample (including to write this blog) took me only about 6 hours. I think you could be really productive with it! In the case I published the documents with mistakes: please leave your comment here!
